Industrial control relays

Omron Relay selection, reduced to the right electrical facts

Compare coil voltage, contact arrangement, socket format and installation needs before requesting a part. A compact path helps panel builders move from circuit requirement to purchasable relay without sorting through unrelated components.

Start Quick SelectBrowse Relays
Technician checking plug-in relays in an industrial control cabinet
V12–220Common coil-voltage search range
AC/DC2 familiesSupply types clearly separated
PIN4–14Socket and terminal formats
DOC1:1Part-level documentation checks

Selection fields

Group the specification before comparing models

Coil and control

Rated coil voltage12 VDC, 24 VDC, 24 VAC, 120 VAC or 220 VAC as required
Supply typeAC and DC coils are treated as distinct selections

Contacts and mounting

Contact arrangementMatch pole count and changeover logic to the control circuit
InstallationPlug-in socket, relay module or panel-compatible base

Market documentation

ApprovalsConfirm applicable markings on the exact requested series and destination market

A short list that prevents long troubleshooting

01

Coil first

Separate operating voltage and AC/DC supply before contact capacity or footprint comparisons begin.

02

Socket compatibility

Check pin count, terminal orientation, retention hardware and available panel depth as one mounting decision.

03

Load context

State whether the relay switches resistive, inductive or pilot-duty loads so contact ratings are interpreted correctly.

04

Traceable request

Include the complete part number and requested documentation to reduce ambiguity around variants and substitutions.

Need circuit-fit guidance?

Share coil supply, contact logic and load details.

Talk to an Engineer

Have a part number?

Send quantity, destination and required date.

Request a Quote
